150L Flat Plate Solar Water Heater(CE,ISO)

Tank and frameFeature: Inner tank: SUS304-2B Food Grade Stainless Steel by argon protect welding, supply water quality and drinkable. Outer tank: Color steel or SUS304Stainless Steel. Heat insulation layer: 50-60mm import polyurethane integral foaming. Frame: Galvanized Steel coated un-corrosion layer, both install inclined and flat roof. High Pressure Cold Water In:6 bar cold water to tank from Feeder or Electric Auto Valve. Flat plate collector Feather: 1. Special Anodized aluminum alloy frame to ensure handsome appearance and can accept high pressure without leakage. 2. Operation Temperature -33°c 120°c 3. Patterned temper glass or low iron temper glass (4mm thickness) is not easy broken with very high transmission and low emission Black chrome or Magnetic blue sputtering coating has very higher absorption rate to ensure the high efficiency. Technology: Absorber Type Absorber fin material Absorber fin dimensions Sputtered surface Feature Absorptivity Emittance Flat plate tube Copper 2000mm×1000mm Black chromium,having selective surface decalescence Absorptivity&Emittance are according to BC091 α=0.93(±0.05) ε=0.12(±0.02) Tube Array Riser to heat layer joint Header to riser joint Header material Header size Riser material Riser size Number of risers Collector socket material Collector socket thread size Maximum torque Connection pip size Supersonic melting solder Copper Silver solder Type C-copper tube, to AS 1432-1973 Φ 25mm OD, 0.71 mm wall thickness Type C-copper tube, to AS 1432-1973 Φ 12 mm OD, 0.40 mm wall thickness 7 Free machining brass 20mm(3/4” BSP) 0.03 kN-m 19.1mm OD ( 3/4”) Weights & Measures Weight empty Weight full Structural pressure test 38kg 40kg 800kPa Specification: ModelLighting(m²)Flat Plate CollectorSupply hot water(L/°C)Qty per 20/40" containerLengthWidthNo.SHFP150L 22000mm1000mm1 150 37/76SHFP300L 42000mm1000mm2 300 21/45
